Feature Description

●2A?2C contact arrangement
●The Height of the product is15.9mm?Suitable for flat mounting
●Breakdown voltage (between coil and contacts):5KV
●UL insulation system:Class F
●Environmental friendly product(RoHS compliant)
●Outline Dimensions:(29.0×19.6×15.9)mm
●Main application:Industrial control,Photovoltaic Inverter
